10 T Cable Drum Plate Rail Transfer Cart for industrial warehouse material transportation
The 10 T Cable Drum Plate Rail Transfer Cart for industrial warehouse material transportation are powered by the cabledrum. The hydraulic lifting device can be installed on the cable roll power material handling equipment. This series’ cable drum power material handling equipment rail transfer cart are suitable to be used in the bad environment, for example, high-temperature and explosive condition.The rail transfer cart's using time is not limited and it has no strict requirements for the railway. The load capacity of the cable drum plate rail transfer cart is not limited and can be used frequently. The running distance of KPJ series can reach to 200m. If the running distance is more than 50m, a cable arranger needs to be installed to arrange the cables.
Functions of 10 T Cable Drum Plate Rail Transfer Cart for industrial warehouse material transportation
- The cable drum power material handling equipment is Anti-explosion,Anti-high temperature;
- With lifting holes, convenient to shipment;
- Stable start, big starting power, long lifetime;
- The cable drum power material handling equipment transfer carrier has no strict requirement for the railway;
- Simple structure, low cost ;
- Running distance can reach to 200m;
- The roll power material handling equipment transfer carrier's using time is not limited;
- Safe and convenient operation ;
- The hydraulic lifting device can be installed on the roll power material handling equipment;
- High using frequency ;
- The cable drum power material handling equipment has Unlimited load capacity.
Detailed Image of 10 T Cable Drum Plate Rail Transfer Cart for industrial warehouse material transportation
Technical parameter table of 10 T Cable Drum Plate Rail Transfer Cart for industrial warehouse material transportation
| Rated Load | 5 | 10 | 15 | 20 | 30 | 40 | 50 |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Wheel Base(mm) | 1500 | 1500 | 1500 | 1700 | 1700 | 1800 | 1800 |
| Turnning Radius(mm) | 2501 | 3101 | 3401 | 3901 | 4301 | 4801 | 5201 |
| Axles Distance(mm) | 2500 | 3100 | 3400 | 3900 | 4300 | 4800 | 5200 |
| Motor Power(Kw) | 3.5 | 5 | 6 | 7 | 10 | 12 | 15 |
| Running Speed(m/min) | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 | 0-12 | 0-12 |
| Cart Weight(t) | 4.3 | 5.3 | 6.6 | 7.9 | 8.8 | 10 | 10.5 |
| Impacted Rated Load(t) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 |
The Scheme of 10 T Cable Drum Plate Rail Transfer Cart for industrial warehouse material transportation
Application of the 10 T Cable Drum Plate Rail Transfer Cart for industrial warehouse material transportation
Stable and flexible during the turning in small space, we have optimized the steering mechanism, wheel press and frame rigidity to make it available for linkage of several trolleys.
