Industry Battery Transfer Cart Trackless Facility Flatform Truck 360 Degree Rotate

Henan Perfect Handling Equipment Co., Ltd.
Contact Now

Industry Battery Transfer Cart Trackless Facility Flatform Truck 360 Degree Rotate

Brand Name : PERFECT

Model Number : BXC

Certification : CE, SASO, SGS

Place of Origin : Xinxiang, China

MOQ : 1 Set

Payment Terms : Western Union, L/C, T/T

Supply Ability : 70 Sets Per Month

Delivery Time : 45 Days

Packaging Details : The body will be packed with tarp, small parts will be put in wooden cases.

Product Name : Automated Rail Transfer Truck

Parameter : Customized

Operation way : Pendant & Remote controller

Running Distance : Unlimited

Color : Yellow/Customized

Power source : Battery

Load capacity : Customized

Warranty : 12 Months

Running speed : 0~20m per minute

Wheel : 4

Special Function : Anti-Explosion, Heat-Resistant, Lifting, Dumpling

Application : Steel Industry, Factory, Warehouse, Port

Contact Now

 Battery Powered Transfer Cart Trackless Facility Flatform Truck For Industry


 Introduction of Battery Powered Transfer Cart

Our this type of transfer carts are powered by battery which installed inside the car. The current is supplied to pulling motor through electric control system thus to make the car start, stop, move forward, move backward, turn around and change speed , etc.The car is also could run on L-type, S-type and curved track. It is easy for this type of car to rotate 360 degree on the cement floor. It is suitable for all kinds of transport occasion since its travel distance is unlimited and low requirement to the track. You just need remember to maintain regularly.
Parameters of Battery Powered Transfer Cart

Model BXC-2t BXC-20t BXC-50t BXC-100t BXC-150t
Rated Load(t) 2 20 50 100 150
Table Size (mm) Length(L) 2000 4000 5500 6500 10000
  Width(W) 1500 2200 2500 2800 3000
  Height(H) 450 550 650 900 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 200 2000
Wheel Diameter (mm) 270 350 500 600 600
Running Speed (m/min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 1 2.2 5 10 15
Battery Capacity 180 180 330 440 600
Battery Voltage 24 48 48 72 72
Running Time When Full Load 4.32 4 3.3 3.2 2.9
Running Distance for One Charge(km) 6.5 4.8 4 3.8 3.2
Recommended Rail Model P15 P24 P43 QU100 QU100


Application Fields of Battery Powered Transfer Cart
We are professional manufacture handling equipment company, we can produce all kinds of transfer cart according our client's requirement. The trailer carts are mainly used to move material from one place to another. Our products are widely applied in metallurgy, manufacture, oil and gas, die shops, shipyards, chemical plant, automotive, mining industry, aerospace, power generation, coil industry, paper mills, metal working, warehouse and so on. Our products are applied in workshop to improve working effciency.
Advantages of Battery Powered Transfer Cart
1. This battery powered transfer cart is no rail so it is flexible to move,it could 360 degree rotate.

2. It is powered by battery so it is save for worker to operate.

3. Running distance is unlimited.

4. Low requirement to the track.

5. Suitable for all kinds of transport occasion.
Industry Battery Transfer Cart Trackless Facility Flatform Truck 360 Degree Rotate
Industry Battery Transfer Cart Trackless Facility Flatform Truck 360 Degree Rotate

Our Company
We are professional design and manufacture transfer cart company in China and in this fields over 15 years. With advanced equipment, excellent engineers and professional workers, we have got the certificates of CE, SGS, ISO. With the development of our company, we start our international business trade and have exported to US,Germany,Thailand,Netherlands,South Africa, Syria, Turkey, Nepal ,
etc. over 50 countries.

Industry Battery Transfer Cart Trackless Facility Flatform Truck 360 Degree Rotate

How to choose a transfer cart?
If you need to move heavy duty goods bay to bay,then you must need our product.There is no doubt that it will improve your working effciency.Please tell us some data as below,we will design a suitable transfer trailer for you.

1. What material/cargo are you going to transfer?

2. What load capacity do you want?

3. What kind of ground does the transfer cart operate on? (rails or cement floor)

4. What’s the specification table size ? (length,width and height)

5. How long is the running distance?

6. How many working hours do you have everyday?

7. Or do you have any other special requirement?(Anti-explosion,anti-high tempearture)
