Workshop 50 Ton Loading Capacity BWP Battery Powered Transfer Cart Apparatus

Brand Name : AGV battery powered transfer cart apparatus

Model Number : AGV battery powered transfer cart apparatus

Certification : CE ISO SGS

Place of Origin : China(mainland)

MOQ : 1 set

Price : USD 4000~8500 set

Supply Ability : 100 sets months

Delivery Time : 20 work days after received balance payment

Packaging Details : trap and wooden case

Product Name : AGV battery powered transfer cart apparatus

Application : Industrial Filed

Warranty : 12 Months

Color : customized

Running speed : 0-20m/min

After-sales Service Provided : Engineers available to service machinery overseas

Contact Now



Workshop Use 50 Ton Loading Capacity BWP battery powered transfer cart apparatus



Our die cart handling vehicle is available in a number of varieties and capacities, from 10 to 300 tons. They are modular in construction and allow movement changes at ground level in all types of industries and applications. Die cart handling vehicles are also named material transfer carts that run on the shop floor level.
The die cart handling vehicle on rails or straight shifts can either be powered by batteries or cable reels. Whereas the directional free movement handling vehicles are better available as battery powered. All our products come in many sizes, styles and capacities designed to suit your operations specific needs.



Workshop 50 Ton Loading Capacity BWP Battery Powered Transfer Cart Apparatus


Technical Parameters

Model 2t 20t 50t 100t 150t
Rated Load(t) 2 20 50 100 150
Table Size(mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Heigth(H) 500 600 700 1000 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 2000 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 0.8 2.5 5.5 11 15
Running Distance(m) 25 30 50 50 50
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Reference Weight(t) 2.5 5.6 7.8 14.1 26.2
Recommended Rail Model P15 P24 P43 QU100 QU100





Applications

The die cart handling vehicle is designed for transporting heavy cargoes or equipment from one bay to another in factory. It can be used indoor or outdoor. The fields include metallurgy, foundry, new factory construction and ship building and so on. With different styles and standard capacities up to 300 tons, we have the solutions you need and each style can be designed for your specific application.
