Mobile Battery Powered Material Transfer Cart Customized Transport Wagon
General Preview of Material Transport Wagon
Our material transport wagon is powered by storaged power. The battery is fitted in the inner of the vehicle. It's elegant, reliable and high efficient. The wheel is made up of polyurethane solid wheels so the wagon has big load capacity and long service time. We use inported battery it's long in working time and high in quality. You need to charge it for 8 hours and then keep it work for over 4 hours. We think it's a right transfer vehicle for you!
Application fields of Material Transport Wagon
Our Transfer vehicle can be used in many different fields. For example:
Paper Making
In the process of paper making, workers need to transport raw materials-wood, transport papaer pulp and finally trasport products. It works smoothly and make sure the maximum safety.
Construction
You can use our transfer wagon to transport construction mateials.
Ship Building
Our transfer vehicle can also be used in ship building industry. We can use our transfer vehicle to transfer heavy steel and carry out other heavy duty tasks.
Air Port
you can use our products to carry heavy cargo from the luggage station to the airplane.
Advantages of Material Transport Wagon
Parameters of Material Transport Wagon
| Model | BWP-5t | BWP-20t | BWP-30t | BWP-40t | BWP-50t |
| Rated Load(t) | 5 | 20 | 30 | 40 | 50 |
| Impacted rated load(t) | 5 | 20 | 30 | 40 | 50 |
| Structure of Frame | Steel plates welded, beam |
| thickness of the steel plate | 8 | 14 | 14 | 16 | 16 |
| Cart weight(t) | 4.3 | 7.9 | 8.8 | 10 | 10.5 |
| Max. wheel load (t) | 2.8 | 5.6 | 7.7 | 10 | 12 |
| Ground requirement | Cement floor or Steel plate ground |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 |
| Table size (mm) | 3000*2000 | 4500*2200 | 5000*2200 | 5500*2300 | 6000*2300 |
| Height of the whole cart (mm) | 450 | 600 | 650 | 700 | 700 |
| Wheel base (mm) | 1500 | 1700 | 1700 | 1800 | 1800 |
| Axles distance (mm) | 2500 | 3900 | 4300 | 4800 | 5200 |
| Turning radius (mm) | 2501 | 3901 | 4301 | 4801 | 5201 |
| Turning type | Turning while driving with no stop |
| Control method for turning | Control button |
| Turning structure | Mechanical |
| Motor power (KW) | 3.5 | 7 | 10 | 12 | 15 |
| Wheel diameter (mm) | 300 (4) | 400 (4) | 400 (6) | 500 (6) | 500 (6) |
| Wheel material | ZG55+hydropurture |
| Running speed (m/min) | 0-15 | 0-12 |
| Brake principle | Electric magnetic brake |
| Ground balance | mechanical automatic adjustment |
| Operation method | With wire or no wire |
| Battery model | D-250 24pieces | D-440 24pieces | D-250 36pieces | D-330 36pieces | D-440 36pieces |
| Charger's installation | Installed on cart | Split-type |
| Cart color | Yellow and warning sign |
| Radar control | 3-0.3 m, Automatic stop for obstacles |
| Other functions | Turning light, night light and power display |
Packing & Shipping
We will try our best to make sure that your products are delivered safely. The body of the cart is packed with tarp, the small parts will be packed with wooden cases. According the table size and quantity, the cart would be carefully fixed and transported by FCL, LCL, Bulk Transportation, Open Top Container, Flat Rack Container and so on.
Contact Information
Help you to choose the most suitable cart
Thank you very much for looking through the information above. If you are interested in our products, please send us an E-mail and tell us the following information. Thank you!
- What material/cargo are you going to transfer?
- What load capacity do you want?
- What kind of ground does the transfer cart operate on? (rails or cement floor)
- What’s the specification table size ? (length,width and height)
- How long is the running distance?
- How many working hours do you have everyday?
- What special requirements do you have?
